Options for LED recessed lighting fixtures, whether installing canless wafer light kits or retrofitting your current can lights, have grown rapidly. Canless wafer LED light kits can be used for remodel or new construction LED recessed ceiling downlight projects. LED retrofit downlights are installed utilizing your existing recessed can housing.
The Lithonia WF4 LED is the ultra slim, low profile, 9.6 watt, 4.7" x 1.1" super thin, round, LED recessed down light with your choice of 3000K or 4000K and the option of a matte white, matte black, or oil-rubbed bronze trim. The WF4 LED 4 inch LED retrofit generates between an amazing 675-765 lumens. The LED module maintains at least 70% light output for 36,000 hours. LED Wafer down light and remote driver are rated for contact with insulation (IC Rated) and wet location approved, making them ideal for a breadth of both indoor and outdoor residential, hospitality, commercial and multifamily applications.
This downlight comes loaded with third party certifications - CSA certified to US and Canadian safety standards, ENERGY STAR® certified, Wet location rated and Air Tight certified in accordance with ASTM E283-2004. The WF4 LED operates on 120V input power via the factory provided, UL recognized, high efficient driver inside the steel remote box with four 7/8" knockouts with slots for pry-out (Note: Not suitable for pulling wires). The ambient operating temperature range is -40°F (-40°C) to +104°F (+40°C). Dimming, down to 10%, is made simple through use of in-wall dimmer switches.
| Manufacturer | Lithonia Lighting | |||
| Lighting Technology | LED | |||
| Color Temperature (Kelvin) | 3000K Warm White | 3000K Warm White | 4000K Cool White | 4000K Cool White |
| Finish Color | Black | Bronze | Black | White |
| MPN | WF4 LED 30K MB M6 | WF4 LED 30K ORB M6 | WF4 LED 40K MB M6 | WF4 LED 40K MW M6 |
| SKU | WF4 LED 30K MB M6 | WF4 LED 30K ORB M6 | WF4 LED 40K MB M6 | WF4 LED 40K MW M6 |
| UPC | 190887358490 | 190887358582 | 190887358513 | 889804672800 |
| Wattage | 9.6 Watts | 9.6 Watts | 10 Watts | 10 Watts |
| Lumens | 675 Lumens | 675 Lumens | 765 Lumens | 765 Lumens |
| Efficiency (Lumens Per Watt) | 70 LPW | 70 LPW | 76 LPW | 76 LPW |
| Power Factor | 0.97 | 0.97 | 0.98 | 0.98 |
| Voltage | 120V | |||
| Input Current | 0.08A | |||
| Frequency | 50/60 Hz | |||
| Dimmable | Yes | |||
| Rated Life | 36,000 Hours | |||
| CRI (Color Rendering Index) | 80 CRI | |||
| THD (Total Harmonic Distortion) | 15.30% | |||
| Housing | Die-Cast Aluminum | |||
| Lens | Polycarbonate | |||
| Incandescent Equivalent | 50 Watts | |||
| Sound Rating | A | |||
| Operating Temperature | -40°C to 104°C | |||
| Dimensions | 6.7" Diameter x 1.1" H | |||
| Certifications | Energy Star | |||
| Environment | Wet Location | |||
| Warranty | 5 Year Limited | |||
