EiKO 2x4 30 Watt 120-277V LED Backlit Flat Panel 4000K 4000K Cool White

EiKO 2x4 30 Watt 120-277V LED Backlit Flat Panel 4000K

DLC Listed

Price

Color Temp

4000K Cool White

Quantity

Please call to confirm availability.

Free Shipping on Orders Over $750

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":43893242233076,"title":"4000K Cool White","option1":"4000K Cool White","option2":null,"option3":null,"sku":"13170","requires_shipping":true,"taxable":true,"featured_image":{"id":39416262754548,"product_id":8087447044340,"position":1,"created_at":"2023-04-17T11:40:22-04:00","updated_at":"2023-04-17T11:40:23-04:00","alt":"EiKO 2x4 30 Watt 120-277V LED Backlit Flat Panel 4000K 4000K Cool White  ","width":1200,"height":1200,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/BP1-2440S-40-U_01.png?v=1681746023","variant_ids":[43893242233076]},"available":true,"name":"2x4 30 Watt 120-277V LED Backlit Flat Panel 4000K - 4000K Cool White","public_title":"4000K Cool White","options":["4000K Cool White"],"price":8461,"weight":3629,"compare_at_price":null,"inventory_management":"shopify","barcode":"031293131706","featured_media":{"alt":"EiKO 2x4 30 Watt 120-277V LED Backlit Flat Panel 4000K 4000K Cool White  ","id":32010395189492,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/BP1-2440S-40-U_01.png?v=1681746023"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

The EiKO LED flat panel are designed for superior backlighting, with its LED arrangement across the entire panel. This efficient design requires no light guide plate, making it lightweight and resilient, even when hung. With 4 knockouts and a 6” junction box for easy access, plus seismic clips for quick installation, this is the perfect light for quick and easy flat panel installation.

This 2x4 30 watt 120-277V LED backlit flat panel, part number BP1-2430S-40-U (13170), is perfect for shallow plenum spaces. Featuring a backlit design that provides direct light without a light guide plate, a high quality PMMA diffuse lens, and a lightweight design, this panel is easy and fast to install. With 3,300 lumens and a 4000K cool white color temperature, you'll get an impressive 110 lumens per watt. It also features 0-10V dimming and a 5 year limited warranty.

Specifications

Manufacturer	EiKO
MPN	BP1-2430S-40-U
SKU	13170
UPC	031293131706
Lighting Technology	LED
Wattage	30 Watts
Voltage	120-277V
Color Temperature (Kelvin)	4000K Cool White
Lumens	3,300 Lumens
Efficiency (Lumens Per Watt)	110 LPW
Dimmable	0-10V Dimming
Beam Angle	120 Degrees
Rated Life	50,000 Hours
CRI (Color Rendering Index)	80 CRI
Power Factor	>0.9
THD (Total Harmonic Distortion)	<20%
Construction	White Powder Coated Aluminum
Lens	Non-yellowing PMMA Diffusing
Fluorescent Equivalent	4 x 32 Watt 4FT T8
Operating Temperature	-20°C to 40°C
Dimensions	47 3/4" L x 23 3/4" W x 1 13/16" H
Certifications	DLC Listed, RoHS Compliant, FCC Compliant, ETL Listed
DLC Product ID	S-2ZDV4T
Environment	Damp Location
Warranty	5 Year Limited

Documents

EiKO LED Backlit Flat Panel Specification Sheet

EiKO LED Backlit Flat Panel Installation Instructions

EiKO LED Backlit Flat Panel DLC Product Listing
