Name: 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement
Brand: Green Creative
SKU: 98246
Price: 28.34 USD
Availability: OutOfStock

Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White

cULus, FCC

Price Save 13%

Color Temp

3000K Warm White

3500K Bright White

4000K Cool White

Quantity

Limited Quantity Available

Free Shipping on Orders Over $750

Most in-stock items ship the same day!

Helping you maximize your green® since 2007!

[{"id":42858261479668,"title":"3000K Warm White","option1":"3000K Warm White","option2":null,"option3":null,"sku":"98244","requires_shipping":true,"taxable":true,"featured_image":{"id":36292608000244,"product_id":7440477651188,"position":1,"created_at":"2021-12-16T09:48:01-05:00","updated_at":"2021-12-16T09:48:02-05:00","alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","width":1000,"height":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082","variant_ids":[42858261479668,42858261512436,42858261545204]},"available":false,"name":"14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement - 3000K Warm White","public_title":"3000K Warm White","options":["3000K Warm White"],"price":2834,"weight":363,"compare_at_price":3262,"inventory_management":"shopify","barcode":"045079982444","featured_media":{"alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","id":28842892132596,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":42858261512436,"title":"3500K Bright White","option1":"3500K Bright White","option2":null,"option3":null,"sku":"98245","requires_shipping":true,"taxable":true,"featured_image":{"id":36292608000244,"product_id":7440477651188,"position":1,"created_at":"2021-12-16T09:48:01-05:00","updated_at":"2021-12-16T09:48:02-05:00","alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","width":1000,"height":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082","variant_ids":[42858261479668,42858261512436,42858261545204]},"available":false,"name":"14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement - 3500K Bright White","public_title":"3500K Bright White","options":["3500K Bright White"],"price":2834,"weight":363,"compare_at_price":3262,"inventory_management":"shopify","barcode":"045079982451","featured_media":{"alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","id":28842892132596,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":42858261545204,"title":"4000K Cool White","option1":"4000K Cool White","option2":null,"option3":null,"sku":"98246","requires_shipping":true,"taxable":true,"featured_image":{"id":36292608000244,"product_id":7440477651188,"position":1,"created_at":"2021-12-16T09:48:01-05:00","updated_at":"2021-12-16T09:48:02-05:00","alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","width":1000,"height":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082","variant_ids":[42858261479668,42858261512436,42858261545204]},"available":true,"name":"14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement - 4000K Cool White","public_title":"4000K Cool White","options":["4000K Cool White"],"price":2834,"weight":363,"compare_at_price":3262,"inventory_management":"shopify","barcode":"045079982468","featured_media":{"alt":"Green Creative 14.5 Watt 4 Pin LED 120-277V PL Horizontal Mount G24q GX24q Direct Replacement 3000K Warm White  ","id":28842892132596,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/www.greenelectricalsupply.com\/cdn\/shop\/products\/Green-Creative-Horizontal-PL-Lamp.jpg?v=1639666082"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Details
Specifications
Documents
Request A Quote

Details

This PL EDGE SERIES lamp has been designed and engineered for demanding commercial applications. This is a plug & play lamp, meaning this lamp is compatible with most 42, 32, and 26 watt electronic ballasts (Direct installation). Simply install it in your existing fixture and turn ON the savings (up to 60% energy savings). These PL LED Titanium light bulbs are designed for horizontal applications.

Here is the Green Creative, 110° beam angle, 4 pin mount retrofit LED. It is a direct replacement for 42w 4-pin G24q and GX24q fluorescent PL single twin tube light bulbs. Part number 14.5PLH/8(XX)/DIR consumes just 14.5 watts of 120 to 277 volt 60 Hz energy. These LED tubes are UL Listed and are dimmable on 0-10V circuits. They will produce 1,700-1,800 lumens A measure of the luminous flux or quantity of light emitted by a source. For example, a dinner candle provides about 12 lumens. of light output, have a Color Rendering Index CRI of 82 and a rated life of up to 50,000 hours . Give them a try - You will be very pleasantly surprised.

The physical dimensions of these LED retrofit bulbs are 6.625 inches MOL by 1.75 inches wide. Note: This light bulb may not fit in all 8" recessed cans. It is recommended a test installation be performed prior to the final installation. Each 14.5PLH/8XX)(/DIR LED fluorescent retrofit bulb operate directly off of your existing electronic ballast.

Specifications

Manufacturer	Green Creative
Color Temperature (Kelvin)	2700K Warm White	3500K Bright White	4000K Cool White
MPN	14.5PLH/830/DIR	14.5PLH/835/DIR	14.5PLH/840/DIR
SKU	98244	98245	98246
UPC	045079982444	045079982451	045079982468
Lumens	1700 Lumens	1750 Lumens	1800 Lumens
Efficiency (Lumens Per Watt)	117 lm/w	121 lm/w	124 lm/w
Lighting Technology	LED
Wattage	14.5 Watt
Voltage	120 - 277V
Bulb Shape	PL
Base	4-Pin G24q & GX24q
Burn Position	Horizontal
Dimmable	Yes, 0-10V Dimming
Beam Angle	110 Degree
Ballast Operation	Type A Ballast Compatible
Rated Life	50,000 Hours
CRI (Color Rendering Index)	82
Fluorescent Equivalent	42 Watt
Operating Temperature	-4° F to 95° F
Dimensions	1.75" Diameter x 6.625" MOL
Certifications	cULus, FCC
Environment	Damp Location
Warranty	5 Year Warranty

Documents

Green Creative Horizontal LED Direct Replacement PL Lamp Specification Sheet

Green Creative Horizontal LED Direct Replacement PL Lamp Installation Instructions

Green Creative Horizontal LED Direct Replacement PL Lamp Dimmer Compatibility

Green Creative Horizontal LED Direct Replacement PL Lamp Ballast Compatibility

Green Creative Horizontal LED Direct Replacement PL Lamp Emergency Ballast Compatibility

Request A Quote

Green Electrical Supply is here to help you maximize your green^® on all your electrical supply purchases.

Looking for a quote or need help finding an item, simply use our Contact Us form to request a quote, get assistance, or provide feedback. If you're more of a talker, feel free to give us a call at 248-276-9640 during our weekday hours from 8 am to 5 pm EST.

Here's a little tip to make your quote request even smoother: don't forget to copy the SKU from above and include it along with the quantity in your request. It's a small detail that ensures we get you the most accurate and efficient service. And, just a heads up, the SKU is dynamic, especially for products with multiple options. So, be sure to choose your required options first to view the precise SKU.
